Semi-Solid Push Pull
Semi-Solid Lithium Ion Push Pull Storage
The Lithium Iron Phosphate (LiFePO4) Battery Series provides a safe, reliable, and compact energy storage solution for residential, commercial, and industrial applications. It supports customized BMS communication protocols and inverter compatibility for seamless system integration. The space-saving design simplifies transportation and installation, while customizable appearance and colors offer flexible OEM solutions to meet specific project requirements.
Key Features of Our Semi-Solid Push Pull Battery
High-Level Security Standard
A ceramic-material versatile diaphragm produces no smoke, fire, or explosion in the puncture test.
Lighter Weight & Smaller Volume
Energy density of at least 170 Wh/kg, around 45% of the weight and volume of a comparable lead-acid battery.
Wide Working Temperature Range
Operates reliably across a -20°C to 60°C range.
APP Intelligent Monitoring
Monitor the battery from the app over Bluetooth or Wi-Fi.
Longer Cycle Life
More than 5,000 cycles at 100% depth of discharge.
BMS Intelligent Management
Built-in reliable BMS with charge and discharge protection and real-time monitoring.
APPLICATION
- •Uninterrupted energy
- •Home backup
- •Hospitals
- •Banks
- •Small businesses
- •Small base stations
- •Backup power systems
- •Data processing centers
| Model | Series | Standard Communication Interface | Voltage (V) | Standard Capacity (Ah) | Standard Power (Wh) | Max Charge Current (A) | Max Discharge Current (A) | BMS (A) | Weight±3% (KG) | Dimensions±2 (mm) | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TLSSS300-51.2 | 51.2V | RS485/RS232/CAN | 51.2 | 300 | 15360 | 200 | 200 | 200 | 117 | 554*252*714 | |
| TLSSS200-51.2 | 51.2V | RS485/RS232/CAN | 51.2 | 200 | 10240 | 100 | 100 | 100 | 85 | 554*292*645 | |
| TLSSS100-51.2 | 51.2V | RS485/RS232/CAN | 51.2 | 100 | 5120 | 100 | 100 | 100 | 50 | 554*162*645 |
