Semi-Solid Rack Mounted
Semi-Solid Lithium Ion Rack Storage
The Semi-Solid Lithium-Ion Tower Energy Storage Battery offers a flexible and scalable energy storage solution in various sizes to meet different energy demands. Its easy-to-install design features customizable panels and a customized BMS communication protocol for intelligent system integration. Supporting parallel expansion, the battery can be easily scaled to increase energy storage capacity as needed.
Key Features of Our Semi-Solid Rack-Mounted Battery
High-Level Security Standard
A ceramic-material versatile diaphragm produces no smoke, fire, or explosion in the puncture test.
Lighter Weight & Smaller Volume
Energy density of at least 170 Wh/kg, around 45% of the weight and volume of a comparable lead-acid battery.
Wide Working Temperature Range
Operates reliably across a -20°C to 60°C range.
APP Intelligent Monitoring
Monitor the battery from the app over Bluetooth or Wi-Fi.
Longer Cycle Life
More than 5,000 cycles at 100% depth of discharge.
BMS Intelligent Management
Built-in reliable BMS with charge and discharge protection and real-time monitoring.
APPLICATION
- •Uninterrupted energy
- •Home backup
- •Hospitals
- •Banks
- •Small businesses
- •Small base stations
- •Backup power systems
- •Data processing centers
| Model | Series | Standard Communication Interface | Voltage (V) | Series/Parallel Connection | Standard Capacity (Ah) | Standard Power (Wh) | Standard Charge Current (A) | Max Charge Current (A) | Standard Discharge Current (A) | Max Discharge Current (A) | BMS | Dimensions±2 (mm) | Weight±3% (KG) | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| JXSSS100-51.2 | 51.2V | 485 232 CAN | 51.2 | 16S1P | 100 | 5120 | 20 | 100 | 20 | 100 | 100 | 4U | 46 |
